从0到1的llvm学习 (4) 间接跳转混淆

思路

间接跳转混淆，就是将汇编的跳转或者跳转指令，变化为通过值计算得到地址，再通过jmp 寄存器的形式的混淆

在现在Agent的能力下，其实单纯的CFF已很容易被分析了，但是遇到复杂的间接跳转控制流时，表现得还是不尽人意

其实无论对于间接混淆还是别的混淆，最关键的一点就是要保证执行流的正常，并在此基础上做调整。

我的方案是·，对于每一个块都有一个key，获取出加密后的后继偏移地址，然后经过一个key XOR解密拿到真实偏移，再加上当前BasicBlock的地址，获得后继真实地址后进行跳转

预处理

那么老套路，我们第一步要做的，就是先获取每一个BasicBlock的后继，判断是直接跳转还是条件跳转（这里仍然暂时不考虑PHI和SwitchInst，因为最终可以降级处理）

先给每一个BasicBlock赋一个Key，毕竟我们不可能直接明文存储后继

这里我用了llvm独有的DenseMap，在处理llvm对象的时候似乎更有优势

std::vector<BasicBlock*> orignalBasicBlocks;
      llvm::DenseMap<BasicBlock*, uint64_t> basicBlockKey;
      llvm::DenseSet<uint64_t> usedKeySet;

      for(BasicBlock& bb: F) {
          orignalBasicBlocks.push_back(&bb);
      }

std::default_random_engine e;
      std::uniform_int_distribution<uint64_t> u(0,0xFFFFFFFFFFFFFFFF); // 左闭右闭区间
      e.seed(time(0));

      for(BasicBlock* BB: orignalBasicBlocks) {
          uint64_t RandomSwitchVal = u(e);
          while(usedKeySet.find(RandomSwitchVal) != usedKeySet.end()) {
              RandomSwitchVal = u(e);
          }
          usedKeySet.insert(RandomSwitchVal);
          basicBlockKey[BB] = RandomSwitchVal;
      }

先处理并存储各Successor的地址

这里注意要跳过entryBlock，因为在llvm pass中它的地址是不能拿来运算的，编译时会直接报错

也就是说默认情况下，entryBlock只能保持原有的形式

BasicBlock* bb = orignalBasicBlocks[i];
         Instruction* terminator = bb->getTerminator();
         if(bb == entryBasicBlock) {
             continue;
         }

         if(isa<ReturnInst>(terminator)) {
             continue;
         }

         auto* Br = dyn_cast<BranchInst>(terminator);
         if(!Br) {
             continue;
         }

然后是对地址值的计算，可以看到获取BlockAddress对象后，还需要通过ConstantExpr::getPtrToInt转化为Constant后才能参与运算

经过多次尝试，这里的存储必要要存放在全局变量，如果存放在栈上，编译出来后将不会看到预计算好的结果，而是它把地址的计算式完整的保留了下来，后继地址直接暴露，起不到任何保护效果

if(Br->isUnconditional()) {
    BasicBlock* successorBlock = terminator->getSuccessor(0);

    BlockAddress* successorBlockAddress = BlockAddress::get(successorBlock);
    BlockAddress* curBlockAddress = BlockAddress::get(bb);
    //errs() << "test\n";
    IRBuilder<> builder(bb);
    //Value* blockAddressValue = builder.CreatePtrToInt(blockAddress, builder.getInt64Ty());
    Constant* curBlockAddressConstant = ConstantExpr::getPtrToInt(curBlockAddress, builder.getInt64Ty());
    Constant* successorBlockAddressConstant = ConstantExpr::getPtrToInt(successorBlockAddress, builder.getInt64Ty());
    Constant* subKey = ConstantExpr::getSub(successorBlockAddressConstant, curBlockAddressConstant);
    Constant* xorKey = ConstantInt::get(builder.getInt64Ty(), basicBlockKey[bb]);
    Constant* secretKey = ConstantExpr::getXor(subKey, xorKey);

    GlobalVariable* globalSubKey = new GlobalVariable(*M, builder.getInt64Ty(), true, GlobalValue::InternalLinkage,secretKey, "subKey" );
    successorsSubKeyMap[bb].push_back(globalSubKey);


}

这里对于条件跳转的处理也类似

else {
               BasicBlock* trueSuccessorBlock = terminator->getSuccessor(0);
               BasicBlock* falseSuccessorBlock = terminator->getSuccessor(1);

               BlockAddress* trueSuccessorBlockAddress = BlockAddress::get(trueSuccessorBlock);
               BlockAddress* falseSuccessorBlockAddress = BlockAddress::get(falseSuccessorBlock);

               BlockAddress* curBlockAddress = BlockAddress::get(bb);
               //errs() << "test\n";
               IRBuilder<> builder(bb);
               //Value* blockAddressValue = builder.CreatePtrToInt(blockAddress, builder.getInt64Ty());
               Constant* curBlockAddressConstant = ConstantExpr::getPtrToInt(curBlockAddress, builder.getInt64Ty());
               Constant* xorKey = ConstantInt::get(builder.getInt64Ty(), basicBlockKey[bb]);

               Constant* trueSuccessorBlockAddressConstant = ConstantExpr::getPtrToInt(trueSuccessorBlockAddress, builder.getInt64Ty());
               Constant* trueSubKey = ConstantExpr::getSub(trueSuccessorBlockAddressConstant, curBlockAddressConstant);
               Constant* trueSecretKey = ConstantExpr::getXor(trueSubKey, xorKey);

               GlobalVariable* globalTrueSubKey = new GlobalVariable(*M, builder.getInt64Ty(), true, GlobalValue::InternalLinkage,trueSecretKey, "trueSubKey" );
               successorsSubKeyMap[bb].push_back(globalTrueSubKey);


               Constant* falseSuccessorBlockAddressConstant = ConstantExpr::getPtrToInt(falseSuccessorBlockAddress, builder.getInt64Ty());
               Constant* falseSubKey = ConstantExpr::getSub(falseSuccessorBlockAddressConstant, curBlockAddressConstant);
               Constant* falseSecretKey = ConstantExpr::getXor(falseSubKey, xorKey);

               GlobalVariable* globalFalseSubKey = new GlobalVariable(*M, builder.getInt64Ty(), true, GlobalValue::InternalLinkage,falseSecretKey, "falseSubKey" );
               successorsSubKeyMap[bb].push_back(globalFalseSubKey);

           }

块处理

上面已经处理好了偏移的计算表达式，并已经存放到全局变量的中了，那么记下来就是取值并计算再跳转的过程

这里要十分注意的是，虽然我们已经通过CreateIndirectBr为块建立了一个terminator指令，但直接编译还是会报错，因为对于编译器来说，它不清楚你的这个计算地址是否有效。

因为需要用indirectInst->addDestination(successorBlock)明确指向一个后继。

/*无条件跳转 */
if(Br->isUnconditional()) {
    /*获取当前块的地址，并转化为可计算值 */
    BasicBlock* successorBlock = terminator->getSuccessor(0);
    BlockAddress* curBlockAddress = BlockAddress::get(bb);
    Value* basicBlockAddressValue = builder.CreatePtrToInt(curBlockAddress, builder.getInt64Ty());

    /*获取加密后的偏移 */
    GlobalVariable* globalSubKey = successorsSubKeyMap[bb][0];
    //Value* gep = builder.CreateInBoundsGEP(builder.getInt64Ty(), globalSubKey, {builder.getInt64(0), builder.getInt64(targetIdx)});
    Value* loadSecretKey = builder.CreateLoad(Type::getInt64Ty(ctx), globalSubKey);

    /*获取当前块的key，并解密出真实偏移*/
    Value* xorKey = ConstantInt::get(builder.getInt64Ty(), basicBlockKey[bb]);
    Value* loadSubKey = builder.CreateXor(loadSecretKey, xorKey);

    /*计算得到真实后继地址，并进行跳转*/
    Value* realBlockAddressValue = builder.CreateAdd(basicBlockAddressValue, loadSubKey);
    Value* realBlockAddress = builder.CreateIntToPtr(realBlockAddressValue, builder.getInt8PtrTy());
    IndirectBrInst* indirectInst = builder.CreateIndirectBr(realBlockAddress, 1);

    indirectInst->addDestination(successorBlock);
    terminator->eraseFromParent();

}

然后条件跳转也类似，唯一不同的就是，从中取出true和false的不同加密偏移，要添加一个当前块Condition下的SelectInst，来选择需要解密的偏移。

/*条件跳转 */
else {
    BasicBlock* trueSuccessorBlock = terminator->getSuccessor(0);
    BasicBlock* falseSuccessorBlock = terminator->getSuccessor(1);
    BlockAddress* curBlockAddress = BlockAddress::get(bb);

    Value* basicBlockAddressValue = builder.CreatePtrToInt(curBlockAddress, builder.getInt64Ty());
    //Value* dynamicKey = builder.CreateLoad(builder.getInt64Ty(), XorKeyGV);
    //int targetIdx = i;
    GlobalVariable* globalTrueSubKey = successorsSubKeyMap[bb][0];
    GlobalVariable* globalFalseSubKey = successorsSubKeyMap[bb][1];

    Value* loadTrueSubKey = builder.CreateLoad(builder.getInt64Ty(), globalTrueSubKey);
    Value* loadFalseSubKey = builder.CreateLoad(builder.getInt64Ty(), globalFalseSubKey);
    //Value* gep = builder.CreateInBoundsGEP(builder.getInt64Ty(), globalSubKey, {builder.getInt64(0), builder.getInt64(targetIdx)});

    /*获取当前块Terminator的Conditon，然后添加一个Select指令*/
    Value* condition = Br->getCondition();
    Value* loadSecretKey = builder.CreateSelect(condition, loadTrueSubKey, loadFalseSubKey);

    Constant* xorKey = ConstantInt::get(builder.getInt64Ty(), basicBlockKey[bb]);
    Value* loadSubKey = builder.CreateXor(loadSecretKey, xorKey);
    //Value* calcSubKey = builder.CreateXor(loadEncrypted, dynamicKey);
    Value* realBlockAddressValue = builder.CreateAdd(basicBlockAddressValue, loadSubKey);
    Value* realBlockAddress = builder.CreateIntToPtr(realBlockAddressValue, builder.getInt8PtrTy());
    IndirectBrInst* indirectInst = builder.CreateIndirectBr(realBlockAddress, 2);

    indirectInst->addDestination(trueSuccessorBlock);
    indirectInst->addDestination(falseSuccessorBlock);
    terminator->eraseFromParent();

    continue;
}
